Frequency Range: DC~6GHz Conductor AWG: 17 Conductor Composition: 1/2.74mm Conductor Outside Diameter: 2.74±0.03mm Insulator Outside Diameter: 7.24±0.15mm Insulator Thickness: 2.3mm Shield Composition: 0.038mm Shield Composition: 24*7/0.16mm Shield Outside Diameter: 7.92mm Jacket Outside Diameter: 10.3±0.2mm Jacket Thickness: 1.2mm Conductor Resistance: 4.6↓Ω/Km Insulation Resistance: 1000↑MΩ/Km Spark Test: 3000V Impedance: 50±3Ω Capacitance: 79±3 PF/M VSWR: 1000~2000MHZ ≤1.2, 3000~6000MHZ ≤1.5
